Sprecher+Schuh Operator Contact Block With Screw Terminals 1N.O 110-120/240/125VAC/DC DIN Rail/Base Mount

Description

Operator Contact Block, 690 Volt AC/DC, 10 Amp, 1 Normally Opened Configuration, Screw Terminal, DIN Rail/Base Mounting, IP65/66, Glass-Filled Nylon/PA6/PA66 Housing, -25 to 70 deg C, 22.5 mm

Key Specifications

Barcode (EAN-13)	9321807230744
SKU	S&SD7-BX10
Brand	Sprecher+Schuh
Range Name	D7
Product Type	Operator Contact Blocks

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	D7 pilot devices offer maximum flexibility and a wide choice for all 22.5 mm operator applications with all type (e-stops, selector switches, pushbuttons, pilot lights and more), colour and contact configurations Aesthetically appealing and modularly designed to make assembly and interchangeability easy Operators exhibit low profile and stylish appearance while maintaining the rugged performance necessary for demanding environments D7P is a plastic operator with a captive black plastic front bezel Constructed of high grade thermoplastics, the D7P operators provide strong chemical resistance making them suitable for use in different environments and strong chemical resistance D7M has a die-cast zinc housing and mounting ring for rugged durability Finished with corrosion resistant chrome plating, the D7M also features a captive shiny metal bezel for a polished appearance
Standard Pack Size	1
UNSPSC Class	39122200
UOM	EA
Vendor Product	D7BX10
Contact Configuration	1 Normally Opened
Current	10 Amp
Housing Material	Glass-Filled Nylon/PA6/PA66
IP Rating	IP65/66
Mounting Method	DIN Rail/Base
Size	22.5 mm
Temperature	-25 to 70 deg C
Terminal Connection	Screw
Voltage	690 Volt AC/DC
