Sprecher+Schuh Rail Terminal Block Screwed 1 Wire 1 Level 35mm Blue

$Sprecher\Sprecher_V7W35.jpg$

Description

Rail Terminal Block, 750 Volt, 138 Amp, 35mm Conductor, 1 Conductor, Wire Strip Length: 17 mm, Tightening Torque: 2.5 N/m, Wiring Format: 1 Conductor, 1 Level, Screw Terminal, Rail Mount, Blue, -40 to 90 deg C, Height: 71 mm, 60 mm Width, 14 mm Depth

Key Specifications

SKU	S&SV7-W35-B
Brand	Sprecher+Schuh
Range Name	V7-W
Product Type	Rail Terminal Blocks

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Designed for ease of wiring, secure connections and durability Comprehensive range, offering a wide array of terminal types for most circuits and functions Terminals accommodate a full range of wire sizes from 0.5 to 70 sq-mm wire cross section Cone shaped guide allows easy wire insertion Specialty terminals including two-level, grounding, diode, isolating, fuse, sensor and thermocouple terminals
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	V7W35B
Current Rating	138 Amp
Colour	Blue
Conductor Size	35mm
Depth	14 mm
Height	71 mm
Number of Conductors	1
Mounting Method	Rail
Number of Levels	1
Tightening Torque	2.5 Nm
Terminal Type	Screw
Voltage Rating	750 Volt
Width	60 mm
Wiring Format	1 Conductor
Wire Strip Length	17 mm
