SolarEdge Home Genesis Inverter 5kW Single Phase SolarEdge Home Network Ready

chevron-left
loader
Loading...

Description

chevron-down
Solar Inverter, 1 Phase Phase, 10000 Watt DC Input, 480 Volt DC Input, 380 Volt DC Nominal, 14 Amp DC Max. Input, 5 kW AC Output, 5000 VA AC Max. Apparent, 184-264.5 Volt, 220-230 Volt, 50/60 Hz +/-5, 23 Amp AC Output, 1 (Adjustable 0.8 Leading-0.8 Lagging) Power Factor, <3% Total Harmonic Distortion, 0.992 Efficiency, 0.99 European Weighted Efficiency, 3000 mtr Max. Altitude, RS485 Ethernet Wi-Fi (Optional), Natural Convection Cooling, <25 dBA, Wall Mounting, IP65, -40 to 60 deg C

Key Specifications

chevron-down
SKU
SLRSE5000H-AUL00BEU4
Brand
SolarEdge
Range Name
Genesis
Product Type
Inverters

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Single string design for inverter up to 5 kW AC
  • Faster, simpler installation with maximum design flexibility
  • Record breaking inverter efficiency for more energy production
  • Specially designed to work with SolarEdge power optimiser for higher energy yield
  • Battery ready solution supporting On-Grid storage
  • IP65 rated suitable for outdoor & indoor installation
  • Rapid inverter commissioning via Smartphone using SetApp
  • Advanced safety features including SafeDC and integrated arc fault protection
  • Compact, lightweight and easy to install
  • Supports Wi-Fi communication(Sold separately)
Standard Pack Size 1
UNSPSC Class 26111600
UOM EA
Vendor Product SE5000H-AUL00BEU4
AC Max. Apparent Power 5000 VA
AC Nominal Voltage 220-230 Volt
AC Operating Frequency 50/60 Hz +/-5
AC Operating Voltage 184-264.5 Volt
AC Output Current 23 Amp
AC Output Power 5 kW
Communication Port RS485 Ethernet Wi-Fi (Optional)
Cooling Method Natural Convection
DC Input Power 10000 Watt
DC Input Voltage 480 Volt
DC Max. Input Current 14 Amp
DC Nominal Voltage 380 Volt
Depth 174 mm
Efficiency 0.992
IP Rating IP65
Height 450 mm
European Weighted Efficiency 0.99
Max. Operating Altitude 3000 Mtr
Noise Level <25 dBA
Mounting Method Wall
Phase 1 Phase
Operating Temperature -40 to 60 deg C
Power Factor 1 (Adjustable 0.8 Leading-0.8 Lagging)
Total Harmonic Distortion <3%
Width 370 mm
