Terasaki Moulded Case Circuit Breaker 4 Pole 160 Amp 690 VAC Front Mount

$Terasaki\Terasaki_P160D24160NN.jpg$

Description

Moulded Case Circuit Breaker, 690 Volt AC/250 Volt DC, 160 Amp, 50/60 Hz, 4 Pole, 250 Frame, Non Auto Switch Trip, Toggle Actuator, Screw, Front Mount, -5 to 70 deg C, 130 mm Height, 120 mm Width, 95.5 mm Depth, 30 mm Pitch

Key Specifications

SKU	TERP160D24160NN
Brand	Terasaki
Range Name	TemBreak Pro
Product Type	MCCBs

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	No trip unit, just to be used as an isolator AC23 and DC23 ratings for motor starting use. No over-current protection (isolator only) Wide range of accessories for application flexibility Accepts standard MCCB internal and external accessories
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	P160D24160NN
Height	130 mm
Depth	95.5 mm
Frequency	50/60 Hz
Frame Type	250 Frame
Current	160 Amp
Actuator Type	Toggle
Number Of Poles	4 Pole
Mounting Method	Front
Please Note	30 mm Pitch
Temperature	-5 to 70 deg C
Terminal Type	Screw
Voltage	690 Volt AC / 250 Volt DC
Trip Type	Non Auto Switch
Width	120 mm
