Terasaki Moulded Case Circuit Breaker 3 Pole 50 kA 20 Amp 690 VAC Front Mount

$Terasaki\Terasaki_P160N2320TM.jpg$

Description

TemBreak PRO MCCBs can be used to provide upstream overload and short circuit back-up protection for downstream load break and ATyS transfer switches. Select an upstream MCCB based on the short circuit level of back-up required. Loadbreak or ATyS transfer switches can be used in various prospective fault current level applications as the upstream MCCB reduces the peak let through current.

Key Specifications

SKU	TERP160N2320TM
Brand	Terasaki
Range Name	TemBreak Pro
Product Type	MCCBs

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Small light and power Main Distribution Boards and Distribution Boards for contractors Light commercial, small offices, consulting suites, shopping centers etc. Low to mid level kA performance levels ratings A mix of pole pitches which only suit specific chassis
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	P160N2320TM
Actuator Type	Toggle
Current	20 Amp
Frame Type	160 Frame
Depth	95.5 mm
Frequency	50/60 Hz
Interrupt Capacity	50 kA
Height	130 mm
Magnetic Setting	120-240 Amp Adjustable
Mounting Method	Front
Number Of Poles	3 Pole
Please Note	30 mm Pitch
Temperature	-5 to 70 deg C
Terminal Type	Screw
Trip Type	Adjustable Thermal Adjustable Magnetic
Thermal Setting	12.5-20 Amp Adjustable
Voltage	690 Volt AC / 250 Volt DC
Width	90 mm
