Treotham 2.5 mm Grey Circular Control Cable Unarmoured PVC/PVC 1mtr

Description

Circular Control Cable, Unarmoured, 2.5 mm, Bare Copper, 0.3-0.5 kV, 12 Core + Earth, 15.1 mm Overall Diameter, 1 mtr Length, 60.4 mm Static/226.5 mm Flexible Bend Radius, >20 MOhm/km Insulation Resistance, Black/White Numerals Core, PVC Insulation, PVC Sheath, Grey Sheath, Static: -40 to 80 deg C/Flexible: -15 to 70 deg C, DIN VDE 0295 IEC 60228 IEC 60332-1

Key Specifications

SKU	TRETA20.0025.12
Brand	Treotham
Range Name	Treoflex
Product Type	Circular Control Unarmoured

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	TA20.0025.12
Bend Radius	Static 60.4 mm Flexible 226.5 mm
Conductor Size	2.5 mm
Conductor Type	Bare Copper
Core Colours	Black/White Numerals
Insulation Material	PVC
Insulation Resistance	>20 MOhm/km
Overall Diameter	15.1 mm
Number of Cores	12 Core + Earth
Sheath Colour	Grey
Sheath Material	PVC
Temperature	Static -40 to 80 deg C Flexible -15 to 70 deg C
Voltage	0.3-0.5 kV
Standards	DIN VDE 0295 IEC 60228 IEC 60332-1
