Unistrut Strut Joining Plate 90 Deg 3 -Hole 57mm Length 90mm Width Stainless Steel
Loading...
Description
Strut Joining Plate, M12, 90 deg Angle, 3 Hole, 14 mm Hole Diameter, 21 mm From End 48 mm On Center Hole Spacing, For Use With 41 mm Width Channel/Strut, Stainless Steel, 57 mm Length, 90 mm Width, 2.5 Safety Factor
Key Specifications
| SKU |
UNSP1458SS
|
|---|---|
| Brand |
Unistrut
|
| Product Type |
Strut & Channel Joiners
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 30101800 |
| UOM | EA |
| Vendor Product | 4013366 |
| Fitting Size | M12 |
| Angle | 90 deg |
| For Use With | 41 mm Width Channel/Strut |
| Hole Diameter | 14 mm |
| Hole Spacing | 21 mm From End - 48 mm On Center |
| Material | Stainless Steel |
| Number of Holes | 3 Hole |
| Please Note | 2.5 Safety Factor |
| Width | 90 mm |
