WWC ViperHiTemp Flexible Cable Double Insulated High Temperature 2 Core & Earth 0.75mm 450/750V Silicone +180C Black

Description

Flexible Cable, Double Insulated, High Temperature, 2 Core & Earth, 0.75 mm, Tinned Annealed Copper, 450/750 Volt, 0.2 mm Strands, 2.3 mm Core Diameter, 6.8 mm Overall Diameter, 34 mm Bend Radius, Conductor Resistance: DC - 26.7 Ohm/km, Silicone Rubber Insulation, Silicone Rubber Sheath, Brown Blue Green/Yellow Cores, Black Sheath, -60 to 180 deg C

Key Specifications

SKU	WWC6975
Brand	WWC
Range Name	ViperHiTemp
Product Type	Flexible Cable High Temperature Double Insulated

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	100
UNSPSC Class	26121600
UOM	MTR
Vendor Product	6975
Bend Radius	34 mm
Conductor Resistance	DC: 26.7 Ohm/km
Conductor Type	Tinned Annealed Copper
Conductor Size	0.75 mm
Core Colours	Brown/Blue/Green/Yellow
Core Diameter	2.3 mm
Insulation Material	Silicone Rubber
Number of Cores	2 Core + Earth
Overall Diameter	6.8 mm
Sheath Material	Silicone Rubber
Sheath Colour	Black
Temperature	-60 to 180 deg C
Stranding	0.2 mm
Voltage	450-750 Volt
