WWC 240mm SDI Cable White 500mtr

Description

SDI Cable, 240 mm, Class 5 Annealed Copper, 0.6-1 kV, 1 Core, 20.8 mm Nominal Diameter, 27.9 mm Overall Diameter, 500 mtr Length, 176 mm During Installation/117 mm After Installation Bend Radius, 1.7 mm Insulation Thickness, 0.0801 Ohm/km Conductor Resistance, White Core, X-90 XLPE Insulation, TPE Sheath, Orange Sheath, -40 to 90 deg C, AS/NZS 5000.1 AS/NZS 3808 AS/NZS 1125 AS/NZS 1660.5.6

Key Specifications

SKU	WWC7824XT-OR
Brand	WWC
Range Name	Conflex
Product Type	SDI Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Mostly used for switchboard wiring, load banks, battery leads, battery chargers, jumper leads, etc.
Standard Pack Size	500
UNSPSC Class	26121600
UOM	MTR
Vendor Product	7824XT-OR
Bend Radius	176 mm During Installation/117 mm After Installation
Conductor Resistance	0.0801 Ohm/km
Conductor Size	240 mm
Conductor Type	Class 5 Annealed Copper
Core Colours	White
Insulation Material	X-90 XLPE
Insulation Thickness	1.7 mm
Nominal Diameter	20.8 mm
Number of Cores	1 Core
Overall Diameter	27.9 mm
Sheath Colour	Orange
Sheath Material	TPE
Standards	AS/NZS 5000.1 AS/NZS 3808 AS/NZS 1125 AS/NZS 1660.5.6
Temperature	-40 to 90 deg C
Voltage	0.6-1 kV
