WWC 240mm SDI Cable White 500mtr
Loading...
Description
Flex Cable, 240 mm, Flexible Aluminium, 0.6-1 kV, 1 Core, 20.8 mm Nominal Diameter, 27.9 mm Overall Diameter, 500 mtr Length, 307 mm During Installation/184 mm After Installation Bend Radius, 1.7 mm Insulation Thickness, 0.0808 Ohm/km Conductor Resistance, White Core, X-HF-110 Insulation, HFS-110-TP LSZH Sheath, Black Sheath, -40 to 110 deg C, AS/NZS 5000.1 AS/NZS 3808 AS/NZS 1125 AS/NZS 1660.5.6
Key Specifications
| SKU |
WWCAL240X2H2
|
|---|---|
| Brand |
WWC
|
| Product Type |
SDI Cable
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 500 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | AL240X2H2 |
| Bend Radius | 307 mm During Installation/184 mm After Installation |
| Conductor Resistance | 0.0808 Ohm/km |
| Conductor Size | 240 mm |
| Conductor Type | Flexible Aluminium |
| Core Colours | White |
| Insulation Material | X-HF-110 |
| Insulation Thickness | 1.7 mm |
| Nominal Diameter | 20.8 mm |
| Number of Cores | 1 Core |
| Overall Diameter | 27.9 mm |
| Sheath Colour | Black |
| Sheath Material | HFS-110-TP LSZH |
| Standards | AS/NZS 5000.1 AS/NZS 3808 AS/NZS 1125 AS/NZS 1660.5.6 |
| Temperature | -40 to 110 deg C |
| Voltage | 0.6-1 kV |
